Allowed length difference for exons

Determines the maximal difference between the length of an exon and the length of the duplicated exon. The length is defined by the number of amino acids coded by the exon.

Minimal score for exons

The score is defined by the global alignment score of the translated exon sequence to the duplicated exon translation divided by the global alignment score of the exon translation to itself. The minimal score is a threshold above which the duplicated exon is taken into account.

Minimal tandem gene score

The score is defined by number of amino acids of the original gene found in the duplicated gene divided by the number of amino acids of the original gene. This means that mismatches are counted, but gaps are not counted.

Minimal exon length

Just exons, which are longer than the minimal exon length, are taken into account for the search for tandem gene duplications. The length is defined by the number of amino acids coded by the exon.

Search for concatenated exons

If this option is enabled, the algorithm searches for duplicated exons with pairs (2-tuples) of neighbouring exons, triplets (3-tuples), 4-tuples, 5-tuples and so on up to all exons by concatenating the translations of the neighbouring exons. So helps to find duplicated exons in which introns are lost.

Search for splitted exons

If this option is enabled, the algorithm searches for exons splitted in two exons in the duplicated gene. Only exons, which were not found in the first round of the algorithm are used for this search. The missing exons are splitted in all possible two parts, whereby the smaller part must be longer than the minimal exon length.

Search with start codon for first exon

The first exon does not have a conserved splice site pattern at the 5' end but its beginning is determined by the start codon (ATG) coding for a Methionin. So the algorithm tries to find duplicated exons beginning with ATG (and not with a splice site pattern at the 5' end of the exon).

• Auto: This option makes it possible to autodetect, whether the first exon in the Scipio result is the beginning of the protein. It searches for duplicated exons with the ATG start codon (instead of a splice site pattern) if the first exon begins at the start of the protein sequence and starts with ATG.
• Enable: This option forces the algorithm to look for alternative exons with ATG as start codon for the first exon (and does not use the splice site pattern).
• Disable: This option forces the algorithm to use splice site patterns of the first exon to look for duplicated exons as if it is a normal exon in the middle.

Search with stop codons for last exon

The last exon does not have a splice site pattern at the 3' end but its end is determined by a stop codon (TAG, TAA, TGA). So the algorithm tries to find duplicated exons followed by a stop codon (and not with a splice site pattern at the 3' end of the exon).

• Auto: This option makes it possible to autodetect, whether the last exon in the Scipio result is the end of the protein. It searches for duplicated exons with stop codons (instead of a splice site pattern) if the last exon ends at the end of the protein sequence and is followed by TAG, TAA or TGA.
• Enable: This option forces the algorithm to look for duplicated exons followed by stop codons for the last exon (and does not use the splice site pattern).
• Disable: This option forces the algorithm to use splice site patterns of the last exon to look for duplicated exons as if it is a normal exon in the middle.
